Product Details:
|
| Output Power: | 51 - 100W | Input Voltage: | 110V/220V |
|---|---|---|---|
| Output Current: | 5A | Output Type: | Single |
| Output Voltage: | 12V | Frequency:: | 50/60Hz |
| Cooling Method:: | Air Cooling | Size:: | 158x97x42 Mm |
| High Light: | 100W 12v 5a switching power supply,80MV 12v 5a switching power supply,100W constant voltage led driver |
||
Product Description
----------------------------------------------------------------------------------------------------------------------------------------
Features:
1.International AC input range
2.High efficiency, low working temperature
3.Short circuit, overload, over-current protection
4.100% fully load burn-in test
5.Built-in EMI filter, low ripple noise
6.Low cost, high reliability
7.CE and ROHs approval
8.OEM and ODM is welcome
Specification
| DC Output | DC Voltage: 12V |
| DC Current : 5A | |
| Ripple & Noise: 80MV | |
| DC Adjustable Range: ±10% Rated Voltage | |
| Voltage Tolerance: ±2.0% | |
| Line Regulation: ±0.5% | |
| Load Regulation: ±1% | |
| Setup,Rise Time,Hold Up Time:200ms,50ms, 20ms/230VAC | |
| AC Input | AC Voltage Range: 85-264VAC |
| Frequency Range: 47-63Hz | |
| Efficiency:90% | |
| AC Current: 0.86/115V 0.4A/230V | |
| AC Inrush Current: 20A/115V 40A/230V | |
| Leakage Current< 0.5mA /240VAC | |
| Protection | Over-load: 105%-150% hiccup mode,Auto-recovery |
| Over-voltage: 115%-135% Cut Off the Output,Auto-recovery | |
| Over-temp. : Shut down O/P voltage, Auto-recovery |
Our Services
Pre-Sales Service
We pay great attention to communication with the customer. We believe that must understand customer needs, combined with professional product knowledge, to provide competitive products to our customers.
Provide details about the product drawing, product parameter, production procedure, product test, product certificate, installation and debugging guide.
Sales Service
Customized solution designs.
Product rendering drawing.
From production process to logistics all-the-way tracking report.
After-Sales Service
Five-year quality warranty with lifelong maintenance.
Free guarantee repair: free repair service during the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.
