Home ProductsConstant Voltage LED Power Supply

RoHS Power Supply Adaptor Switching Led 12v 5a AC To DC

Certification
China shenzhen Ever Advance Technology Limited certification
China shenzhen Ever Advance Technology Limited certification
I'm Online Chat Now

RoHS Power Supply Adaptor Switching Led 12v 5a AC To DC

RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC
RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC

Large Image :  RoHS Power Supply Adaptor Switching Led 12v 5a AC To DC

Product Details:
Place of Origin: Guangdong
Brand Name: Advance Lighting
Certification: CE
Model Number: ALL-AD12-60W
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1) Vacuum packing 2)Special Protect carton for exporting product. 3)Packing as customer requirement
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100000pcs/M

RoHS Power Supply Adaptor Switching Led 12v 5a AC To DC

Description
Output Power: 60W Input Voltage: 110V/220V
Output Current: 5A Output Type: Single
Output Voltage: 12V Frequency: 50/60Hz
Cooling Method: Air Cooling Application: LED Lighting
High Light:

RoHS power supply adaptor switching led 12v 5a

,

power supply adaptor switching led 12v 5a

,

RoHS 5A ac to dc adapter

Advance Lighting High quality 12v 5amp led power supply 60w adaptor 220v ac desktop convertor

Product Description

-------------------------------------------------------------------------------------------------------------

Features:

1. Universal Input 100~240VAC 50/60Hz

2. over voltage protection: 120%min

3. over current protection: 120%min

4. over protection

5.Short-circuit protection: automatic recovery

6. Load regulation: ± 5%

7. High Efficiency

8.TWO YEAR WARRANTY



Specification

Input
Voltage Range
90~264Vac(Normal Reated Input Voltage is 100~240Vac)
Frequency Range
47/63Hz
Efficiency
85%min
Output
DC Voltage
12V
Rated Current
5A
Rated Power
60W
Voltage Tolerance
±5%
Line Regulation
±1%
Load Regulation
±5%
Enviroment
Working Temp
-10~+65
Working Humidity
20~90% RH non-condensing
Storange Temp., Humidity
-20~+85, 10~95%RH
Others
Certificates
CE-EMC CE-LVD RoHS
DC plug
5.5x2.1mm, 5.5x2.5mm
Packing
Brown paper box, with AC cable



RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC 0

RoHS Power Supply Adaptor Switching Led 12v 5a  AC To DC 1



Our Services



Pre-Sales Service

We pay great attention to communication with the customer. We believe that must understand customer needs, combined with professional product knowledge, to provide competitive products to our customers.
Provide details about the product drawing, product parameter, production procedure, product test, product certificate, installation and debugging guide.

Sales Service
Customized solution designs.
Product rendering drawing.
From production process to logistics all-the-way tracking report.

After-Sales Service
Five-year quality warranty with lifelong maintenance.
Free guarantee repair: free repair service during the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.



FAQ

-----------------------------------------------------------------------------------

Q1. Can I have a sample order for adaptor?

A: Yes, we welcome sample order to test and check quality.



Q2: Do you offer guarantee for the products?
A: Yes, all the power adapter come with 3-5 years warranty.


Q3. Do you have certificates for your products?
A: Yes, we have UL/CUL, FCC, RoHS, CE, KC, SAA, TUV GS, PSE, KCC, NOM, S-Mark, BSMI Certifications.


Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.


Q5. What's your payment item?
A: Our standard payment is T/T in advance, Credit Card, E-Checking.


Q6. Is it OK to print my logo on adaptor?
A: Yes. Please inform us formally before our production and confirm the design firstly.


Q7: How to deal with the faulty?
A: Firstly, our products are produced in strict quality control system and the defective rate will be less than 0.3%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
